BYD Battery-Box HVM+ 2.76kWh Battery Module
Product code : 78004-SN
11816BYD Battery-Box HVM+ 2,76kWh Battery Module to compose 1 Battery-Box HVM+ stack from 3 to 8 HVM+ Battery Modules in series. Ability to scale by adding HVM+ modules later.
You can contact us for more information via the button “add to Wishlist'
BYD Battery-Box HVM+ 2.76kWh Battery Module
Product description

BYD Battery-Box HVM+ 2.76 kWh Battery Module
The BYD Battery-Box HVM+ 2.76 kWh module forms the foundation of the entire HVM+ range. This high-voltage module is used in a stackable configuration to build a complete BYD HVM+ battery tower. Thanks to its modular architecture, every installation is fully scalable – from small residential home batteries to larger energy storage systems for light commercial applications.
Powerful and safe LFP technology
Each 2.76 kWh module uses LiFePO₄ (LFP) cells, globally praised for their safety, stability, and long lifespan. This makes the module not only reliable but also ideal for daily intensive use in modern PV installations.
Modular and flexible design
The HVM+ 2.76 kWh battery module is designed to be stacked easily without internal wiring. The patented BYD plug-in system ensures:
- Fast and safe installation
- No risk of incorrect internal wiring
- Easy expansion by adding additional modules
- Possibility to connect multiple full towers in parallel
BYD Battery-Box HVM+ 2.76kWh Battery Module
Product specifications
Depth (mm)
282
Depth of discharge (usable capacity)
95%
Chemistry of the battery
LFP (Lithium Iron Phosphate)
Height (mm)
240
Storage (kWh)
2.76
Brand
BYD
Factory Warranty (Year)
10
Width (mm)
610
Reference
HVM+
Category
Batteries
