Sigen SigenStack BAT 12.0

Product code : 49112-SN

The SigenStack 12kWh battery is a powerful and secure energy storage solution for both commercial and industrial applications.

You can contact us for more information via the button “add to Wishlist'

Configure → Necessary Accessories

Sigen SigenStack BC M2-0.5C Business Controller

Sigen SigenStack BC M2-0.5C-BST Business Controller

Sigen SigenStack BAT 12.0

Product description

Sigen SigenStack BAT 12.0

The SigenStack BAT 12.0 by Sigenergy is an advanced modular battery solution designed to meet commercial and industrial energy storage needs. With a capacity of 12.06 kWh per module, the system offers flexibility and scalability up to 253 kWh per system, making it ideal for a wide range of applications.

Main Features

✔ Modular and Stackable Design: Supports up to 7 modules per stack and 21 modules per system, allowing easy expansion without complex wiring.
✔ High Energy Capacity: 12.06 kWh per module with a 10,000-cycle lifespan for long-term reliability.
✔ Advanced Safety Features: Six layers of protection including smoke detection, temperature monitoring, fire suppression systems, and IP66 rating for dust and water resistance.
✔ Efficient Energy Management: Nominal charge/discharge rate of 0.5C and max rate of 1C, with a wide operating voltage range of 550–1100V.
✔ Compatibility: Seamless integration with Sigenergy C&I Hybrid Inverter Series and support for DC-coupled solar energy systems.
✔ User-Friendly: Easy installation with no heavy equipment required, automatic device recognition, and real-time monitoring via Sigen Cloud.

Sigen SigenStack BAT 12.0

Product specifications

Cycles

10,000

Depth (mm)

363

Height (mm)

300

Chemistry of the battery

LFP (Lithium Iron Phosphate)

Storage (kWh)

12.06

Brand

Sigen

Factory Warranty (Year)

10 years after connecting with Sigen cloud

Width (mm)

770

Reference

SigenStack BAT 12.0
